Each Bigfoot speaker:

• Weight: 64 lbs
• Dimensions: (Height x Width x Depth)
  68.5" x 14" x 23" Opened
  42.5" x 14" x 23" Closed
• Coverage:
  * area: approximately 150' x 150'
  * crowd size: approximately 2500

Bigfoot speakers include line array components:

• Five 8” neodymium woofers
• One neodymium compression

Technical Specifications

• Rated Power Output: 300 watts
• Max SPL @ Rated Power: 130 dB @ 1 meter
• Frequency Response: 100 Hz ~ 15 kHz ± 3dB
• AC Power Reqs:
  100~240 VAC, 50/60 Hz, 3.5A
• Charger/Power Inlet: PC-2
• Battery
  Three 12V Lithium Iron Phosphate (LiFePo4) rechargeable batteries, 7.5 Ah each
  Full recharge: ~ 5 hours
• AnchorLink Wireless Frequency:
  1920~1930 MHz USA/CAN
  1880~1900 MHz Europe
• AnchorLink Wireless Range: 300’+ line of sight
• AnchorAir Frequency Range:
  1.9 GHz DECT 6.0 USA/CAN
  EU-DECT Europe
• AnchorAir Wireless Range: 300’+ line of sight
• Microphone Inputs:
  * Lo-Z, balanced, XLR & 1/4”
  * 34 V DC condenser mic (phantom) power
  * Hi-Z (10 kΩ), unbalanced, 1/4” phone
• Line Inputs:
  * One unbalanced 1/4”
  * One 3.5 mm stereo
• Speaker Output (post fader): Isolated, 600Ω
  One 1/4” phone


All Bigfoot systems include:

✅ Three built-in rechargeable lithium-ion batteries (7+ hours of playtime)

✅ Class 1 Bluetooth with 150' range so you can stream audio right to your speaker

✅ Line array components that include five 8” neodymium woofers, and one neodymium compression driver

✅ Two balanced 1/4" XLR combo inputs for wired microphones, one 1/4" unbalanced Line In for mixers and instruments, one 1/4" Line Out for connecting companion speakers

✅ Folding design that's easy to set up with just one person

✅ Rugged, weatherproof case designed to keep your electronics safe when you play or transport your speaker

✅ Heavy-duty wheels designed to go everywhere

✅ Anchor Audio 6-4-2 Warranty

Anchor Audio's 6-4-2 Warranty covers;

• All speaker systems for 6 years
• Lithium-ion batteries for 4  years, and
• Microphones and peripheral products for 2 years.

If your warranty expires, we will not leave you high and dry. We will support you and offer an upgrade path, if you're looking to get new gear.
